Pacifica V6-3.8L VIN L (2005)
Curtain Airbag Front Attachment
6. Disengage the side curtain airbag front tether plastic retainer from the hole in the upper A-pillar.
7. Grasp the extruded curtain airbag firmly and pull it straight away from the body far enough to disengage all the plastic push-in fasteners that secure
it to the locating holes in the roof side rail.
8. Remove the curtain airbag from the vehicle as a unit.
INSTALLATION
1. Position curtain airbag over retaining holes in roof rail and firmly snap into place.
2. Engage the side curtain airbag front tether plastic retainer to the hole in the upper A-pillar.
3. Connect the curtain airbag squib connector.
4. Install the screws that secure the curtain air-bag to the spring nuts in the roof side rail.
5. Install the headliner into the vehicle.
WARNING: DO NOT CONNECT THE BATTERY NEGATIVE CABLE. FAILURE TO DO SO COULD RESULT IN OCCUPANT
PERSONAL INJURY OR DEATH.
6. Verify vehicle and system operation.
7. Close hood.
HEAD IMPACT COUNTER MEASURES
REMOVAL
1. Disconnect and isolate the battery negative cable.
2. Wait two minutes for the system reserve capacitor to discharge before beginning any system or component service.
3. Remove the headliner from the vehicle.
4. Remove the curtain airbag.
