Sebring Convertible V6-2.7L (2009)
Refrigerant Oil: Capacity Specifications
REFRIGERANT OIL CAPACITIES
COMPRESSOR OIL DRAIN PROCEDURE - DENSO 6SEU16 VARIABLE DISPLACEMENT
CAUTION: Be certain to adjust the refrigerant system oil level when replacing an A/C compressor. The refrigerant oil in the Denso 6SEU16
A/C compressor can only be drained using the procedure described below. Failure to properly drain the refrigerant oil from the
A/C compressor can prevent the A/C system from operating as designed and cause serious compressor damage.
If the Denso 6SEU16 A/C compressor is being replaced, some refrigerant oil must first be drained from the new A/C compressor. The 6SEU16 A/C
compressor is filled with 100 milliliters (3.4 oz.) from the factory. Drain 60 milliliters (2.1 oz.) of refrigerant oil from the new 6SEU16 compressor. Use
the following procedure to drain and measure refrigerant oil from the Denso 6SEU16 A/C compressor.
