Sebring Sedan L4-2.4L VIN X (2001)
Alignment: Specifications
Front Wheel Alignment
Camber
Preferred
+0.1 deg
Acceptable
-0.5 to +0.7 deg
Cros Camber
Preferred
0.0 deg
Acceptable
0.7 deg
Caster
Preferred
+3.1 deg
Acceptable
+2.1 to +4.1 deg
Cross Caster
Preferred
0.0 deg
Acceptable
1.0 deg
Toe (Right or Left) Preferred
+0.05 deg
Acceptable
-0.05 to +0.15 deg
Total Toe
Preferred
+0.1 deg
Acceptable
-0.1 to +0.3 deg
Curb Height
28.0 +/- 0.75 in
Rear Wheel Alignment
Camber
Preferred
-0.1 deg
Acceptable
-0.5 to +0.3 deg
Toe (Right or Left) Preferred
+0.05 deg
Acceptable
-0.05 to +0.15 deg
Total Toe
Preferred
+0.1 deg
Acceptable
-0.1 to +0.3 deg
Thrust Angle
Preferred
0.0 deg
Acceptable
0.0 +/- 0.15 deg
Curb Height
28.0 +/- 0.75 in
