Town & Country Van AWD V6-201 3.3L VIN R FI (1991)
Wiper Switch: Service and Repair
Fig. 6 Instrument cluster bezel
FRONT STANDARD COLUMN
Refer to Vehicle Lighting/Turn Signals/Turn Signal Switch/Service and Repair for washer/wiper switch replacement procedure.
TILT COLUMN
1.
If equipped, disarm airbag system. Refer to MAINTENANCE PROCEDURES.
2.
Remove warning indicator grille, by prying up with a screwdriver.
3.
Remove three warning indicator modulator screws, then the modulator.
4.
Remove steering column cover, set parking brake, then place gear selector lever into low position.
5.
Remove cluster bezel, then disconnect wiper switch wire connectors.
6.
Remove switch by unsnapping from back side of cluster bezel.
7.
Reverse procedure to install.
