Lanos S Sedan L4-1.6L DOHC D-TEC MFI (2001)
Alignment: Specifications
Alignment
Camber
Front -1 Deg. 10' To 20'
Rear
-2 Deg. 10' To -1 Deg. 10'
Caster - Manual Str'g
Front 30' To 2 Deg. 30'
Rear
---
Caster - Power Str'g
Front 1 Deg. 45' To 3 Deg. 45'
Rear
---
Toe-In At Each Wheel (2-Person Load) Front -10' To 10'
Rear
-10' To 40'
Difference Between Left and Right
Camber
Front 1 Deg. Maximum
Rear
30' Maximum
Caster
Front 1 Deg. Maximum
Rear
---
Toe-In
Front ---
Rear
15' Maximum
Trim Height
Rocker Panel, Front To Ground
195 mm
Rocker Panel, Rear To Ground
191 mm
