Washer Fluid Level Switch: Diagrams (page 2 of 2)
- Make
- Dodge
- Model
- B250 3/4 Ton Van
- Engine
- L6-225 3.7L
- Year
- 1984
- Section
- Sensors and Switches - Wiper and Washer Systems › Washer Fluid Level Switch › Diagrams
Sensors and SwitchesDiagram Information and Instructions · page 2 of 2
Washer Fluid Level Switch: Diagrams (page 2 of 2) – diagram from the Sensors and Switches chapter of the Dodge B250 3/4 Ton Van L6-225 3.7L (1984) factory manual.
Fig. 41 Low Washer Fluid Lamp Wiring Circuit. 1984
