Front Alignment Specifications

Make

Dodge

Model

Charger

Engine

L4-135 2.2L SOHC

Year

1984

Section

Alignment › Specifications › Front Alignment Specifications

MaintenanceFront Alignment Specifications · page 1 of 2

Alignment: Specifications
Front

Front

Camber

Left

- 1/4 to + 3/4 deg









Right - 1/4 to + 3/4 deg











Camber Desired

Left

5/16 deg









Right 5/16 deg













Toe

Note: 7/32'' out to 1/8'' in (.4 deg. out to .2 deg. in).
