Alignment: Specifications
- Make
- Dodge
- Model
- D250 D 250 Pickup
- Engine
- L6-359 5.9L DSL
- Year
- 1992
- Section
- Alignment › Specifications
Alignment: Specifications
Acceptable Alignment Range Camber
0 to +1 deg
Caster
+1 to +2 deg
If vehicle wanders caster should be increased. If steering
effort is very high, especially when cornering, caster
should be decreased.
Turn Angle (Base Tire) Left and Right
33 deg
Toe-In (At Hub Height)
0 to + 0.50 deg
Preferred Settings
Camber
+1/2 deg
Caster
+1/2 deg
If vehicle wanders caster should be increased. If steering
effort is very high, especially when cornering, caster
should be decreased.
Turn Angle (Base Tire) Left and Right
33 deg
Toe-In (At Hub Height)
0.25 deg
