Dakota 2WD V8-4.7L VIN N (2001)
Flywheel: Specifications
Torque Specifications
Torque Specifications
Engine
Component
Torque
2.5 L
Flywheel Bolts
Tighten to 68 Nm. Turn an additional 60 degrees.
New bolts MUST be used when installing the flywheel or
converter plate.
3.9 L
"
75 Nm (55 ft. lbs.)
4.7 L
"
60 Nm (45 ft. lbs.)
Follow the tightening sequence in the image provided.
5.9 L
"
75 Nm (55 ft. lbs.)
