Dakota 4WD V6-3.7L VIN K (2005)
Alignment: Specifications
ALIGNMENT
NOTE: All alignment specifications are in degrees.
RIDE HEIGHT
Front
Difference between spindle and control arm bolt to ground ........................................................................................................................... 71 mm ± 6 mm
Rear
9.25 axle ...................................................................................................................................................................................................... 148 mm ±10 mm
8.25 axle ..................................................................................................................................................................................................... 154 mm ±10 mm
