Cargo Lamp: Locations

Component ID:

175

Component :

LAMP-CARGO

Connector:

Name :

LAMP-CARGO

Color :

WHITE

# of pins :

2

Qualifier :

(LX48)

Pin

Circuit

Description

  1

G78 20VT/OR

DECKLID/LIFTGATE AJAR SWITCH SENSE

Pin

Circuit

Description

  1

G78 20BK

DECKLID/LIFTGATE AJAR SWITCH SENSE

  2

A117 20RD/DG

FUSED B(+) (I.O.D.)

Component Location - 66
