10 EngineDismantling at the bench

Dismantling at the bench

10.

Modified components in relation to the previous 1300 Diesel version

When overhauling the engine at the bench, follow the repair procedures illustrated in the “Overhauling Diesel engines” manual (print no. 504.591) under the Section 1300 cc. The following engine components differ from those illustrated in the above mentioned publication:

1. Timing side engine support
2. Cooling duct from pump to thermostat
