Accelerator control cable - r + r

Operation 1068A30 · ACCELERATOR PEDAL CONTROL

1.1

Removing

- 1048A10 air cleaner filtering element - replace

1. Release the accelerator cable (1b) working on the throttle valve (1a).

2. Disconnect the accelerator cable from the mounting bracket.

1.2 8v

Removing

- 1048A10 air cleaner filtering element - replace

1. Release the accelerator cable (1b) working on the throttle valve (1a).

2. Disconnect the accelerator cable from the mounting bracket.

1.1

1. Disconnect the cable from the accelerator pedal.

Remove the accelerator cable, disconnecting it from the rubber cable duct on the bodyshell and from the mounting bracket.

1.2 8v

1. Disconnect the cable from the accelerator pedal.

Remove the accelerator cable, disconnecting it from the rubber cable duct on the bodyshell and from the mounting bracket.

1.1

Refitting

Position the accelerator cable on the mounting bracket and fit it on the butterfly valve.

Fit the rubber cable duct on the bodyshell and connect it to the accelerator pedal.

- 1048A10 air cleaner filtering element - replace

1.2 8v

Refitting

Position the accelerator cable on the mounting bracket and fit it on the butterfly valve.

Fit the rubber cable duct on the bodyshell and connect it to the accelerator pedal.

- 1048A10 air cleaner filtering element - replace
