Radio - component location

Make

Fiat

Model

Panda Factory Service Manual

Year

2003–2012

Section

Radio accessories › Radio - component location

Wiring diagrams and electrical functionsRadio - component location

RADIO - COMPONENT LOCATION

Component location

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit	5505C
B2	Junction unit under dashboard	5505C
C20	Passenger side dashboard earth
C30	Left rear earth
D110	Clock spring and steering wheel controls coupling
D20	/Rear dashboard coupling
D20	Rear dashboard coupling
D30	Front left door connection
D31	Front right door connection
D35	Rear left door connection
D36	Rear right door connection
D97	Short circuiting coupling
H1	Ignition switch	5520A
M1	Body computer	5505A
M94	Radio Receiver Node
P25	Aerial amplifier/power supply	5570T
P25	Aerial amplifierpower supply	5570T
P35	Speaker in left front door	5570T
P36	Speaker in right front door	5570T
P40	Speaker in rear left door	5570T
P41	Speaker in rear right door	5570T
P45	Front left tweeter speaker
P46	Front right tweeter speaker
P75	CD / multi-player
P75	CD multi-player
P92	Subwoofer
