Bronco II 4WD V6-171 2.8L (1985)
Alignment: Specifications
Camber
Note: Side to side camber readings must be within .7 deg,
when truck frame to axle riding height is within .16 inch
side to side.
Ride Height
2.75 in
-1 7/8 to -3/8 deg
2.95 in
-1 3/8 to +1/8 deg
3.15 in
-7/8 to +3/4 deg
3.35 in
-3/8 to +1 1/8 deg
3.55 in
+1/8 to +1 3/4 deg
3.75 in
+5/8 to +2 1/8 deg
3.95 in
+1 1/8 to +2 5/8 deg
4.15 in
+1 3/4 to +3 1/8 deg
4.35 in
+2 1/8 to +3 5/8 deg
4.55 in
+2 3/4 to +4 deg
