Contour V6-153 2.5L DOHC (1996)

Page 1
background image

Diagnostic Connector - ABS: Locations

Engine View

The Anti-Lock Brake System Diagnostic Connector is located at the LH rear of the engine compartment, mounted to the strut tower.
