Contour V6-153 2.5L DOHC (1996)
2
Install the timing chain tensioner and bolts.
CAUTION: The crankshaft keyway must be in the 11 o'clock position prior to installation of the LH cylinder roller finger followers.
Failure to do so may lead to engine damage.
NOTE:
-
Verify that all timing marks are in the correct position before installing the roller finger followers.
-
Roller finger followers must be installed in their original locations.
-
Lubricate the roller finger follower with engine assembly lubricant D9AZ-19579-D.
16. Install the LH roller finger followers.
CAUTION: Do not install LH cylinder head camshaft journal thrust caps until camshaft journal caps are installed or damage to the thrust caps
may occur.
NOTE: With LH cylinder head roller finger followers installed, align camshaft endplay using thrust caps as a guide prior to torquing journal caps.
17. Tighten the LH camshaft cap bolts in the indicted sequence in several passes.
