Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)

Page 3
background image

2. Note:  The main control valve body bolts will be tightened in later steps.

Loosely install the bolts.

3. Note:  The main control valve body bolts will be tightened in later steps.

Loosely install the bolts.

4. Install the manual control valve detent lever spring.
