Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
-
Using the special tool, make sure the differential bearing shims are fully seated and the assembly turns freely.
16. Install the bearing caps and bearing cap bolts.
17. Use the special tool to verify the backlash.
-
The specification shown in the illustration is the total allowable range.
18. Install the axle shafts.
Differential Case and Ring Gear-Conventional
Special Tools
Disassembly
1. Remove the differential case.
