Ranger 2WD L4-134 2.2L DSL (1983)
Alignment: Specifications
Camber
Note: Side to side camber readings must be within .7 deg.,
when truck frame to axle riding height is within .12 inch
side to side.
Stamped Axle
Ride Height
2.75 in
-1 to -3/4 deg
2.95 in
-1 to -1/4 deg
3.15 in
-1 to +1/8 deg
3.35 in
-5/8 to +5/8 deg
3.55 in
-1/8 to +1 1/8 deg
3.75 in
+3/8 to +1 5/8 deg
3.95 in
+7/8 to +2 1/8 deg
4.15 in
+1 3/8 to +2 3/4 deg
