Drive Belt: Specifications
Drive Belt Routing
New Or Used Belt (Measured At "A") ............................................................................................................................... 480-586 Newtons (108-132 lbs)
Allowable Minimum ......................................................................................................................................................................... 480 Newtons (108 lbs)
