Cruise ControlAdjustments
Cruise Control Servo Cable: Adjustments
Fig. 5 Servo Cable Adjustment
Loosen servo cable clamp locknut. Adjust servo cable casing to place a light tension on servo cable, Fig. 5. Ensure tension on servo cable is not
pulling the throttle off idle setting. Tighten servo cable clamp locknut.
