Seat Heater: Locations
Passenger Compartment/Roof Component Views
Under the Driver Seat Components
1 - Seat Motors - Driver (AG1)
2 - Seat Adjuster Switch - Driver X1 (AG1)
3 - Seat Adjuster Switch - Driver X2 (AG1)
4 - Seat Motors - Driver Connector (AG1)
5 - Lumbar Pump Motor - Driver (AG1)
6 - X307 (AG1)
7 - X314
8 - Heater Element Seat Back - Driver (KA1)
9 - X319 (KA1)
10 - Recliner Motor
11 - Heated Seat Module - Driver (KA1)
12 - Seat Belt Buckle - Driver
13 - Inflatable Restraint Seat Position Sensor (SPS) - Left
Passenger Seat Components - 1 of 2
