Timing Component Alignment Marks: Locations
- Make
- GMC
- Model
- Canyon 4WD
- Engine
- L5-3.7L
- Year
- 2007
- Section
- Timing Component Alignment Marks › Locations
MaintenanceLocations
Timing Component Alignment Marks: Locations
The dark links (1) on the chain should be aligned with marks on sprockets as shown.
