Child Seat: Service and Repair
Child Seat Restraint System Belt Bracket Replacement
Removal Procedure
1. Remove the bolt securing the child seat restraint bracket to the vehicle.
2. Remove the child seat restraint bracket from the vehicle.
Installation Procedure
1. Position the child seat restraint bracket by hooking the 2 tabs on the rear of the bracket into the slots in the vehicle.
Notice: Refer to Fastener Notice.
2. Install the bolt which retains the child seat restraint bracket to the vehicle.
