Wiper Switch: Locations

Instrument Panel/Center Console Component Views

Behind the Center of the I/P Components (W49)

1 - Cigar Lighter
2 - Rear Window Wiper/Washer Switch
3 - Instrument Panel Harness
4 - Auxiliary Power Outlet - Front

Behind the Center of the I/P Components (Z88/Z89)
