All Other Service Bulletins for Input Shaft:|83I88 > < A/T - THM 700-R4 New Input Housing and Shaft Assembly
Page 2
background image

1.

Only the new input housing and shaft assembly is available for service. The check valve retainer and ball assembly will be
available at a later date. Refer to the parts manual for correct part numbers and model applications.

2.

The check valve retainer and ball assembly must not be installed in the past input housing and shaft assembly. Damage to the
piston or housing lip seal surface could result.
