Body and FrameService and Repair · page 1 of 2
Cowl: Service and Repair
Air Inlet Grille Panel Replacement
Removal Procedure
1. Raise and support the hood.
2. Remove the screws (1-7), retaining the air inlet grille panels to the cowl vent.
3. Remove the wiper arms from the vehicle.
4. Disconnect the washer hoses from the air inlet grille panel.
5. Remove the air inlet grille panels from the vehicle.
Installation Procedure
1. Install the air inlet grille panels to the vehicle.
