Grille: Service and Repair – Honda Civic Si L4-2.0L (2004)

Grille: Service and Repair

Front Grille Replacement

1. Remove the front bumper.

2. Remove the front grille (A). Take care not to scratch the front bumper (B).

1. Remove the screws (C).
2. Remove the clips (D).
3. Release the bottom hooks (E) of the grille.
4. Pull out the bottom of the grille to release the upper hooks (F).
5. Pull out the grille to release the slits (G) from the ribs (H), then remove the grille.

3. Install the grille in the reverse order of removal, and note these items:

-

Replace any damaged clips.

-

Push the clips into place securely.

4. Reinstall the front bumper.
