Pilot 4WD V6-3.5L (2008)
Rear Door Latch: Service and Repair
Rear Door Latch Replacement
NOTE: Put on gloves to protect your hands.
1. Remove these items:
-
Door panel
-
Plastic cover, as necessary
-
Rod protector
2. Raise the glass fully.
3. Disconnect the outer handle rod (A) from the joint bushing (B) and lock rod (C) from the joint bushing (D). Detach the inner handle rod (E) from
the rod holder (F), and disconnect the actuator connector (G). Take care not to bend any of the rods.
NOTE: Check for damaged or stress-whitened joint bushing, and replace if necessary.
4. Remove the screws securing the latch (H).
5. Disconnect the inner handle rod (A) from the joint bushing (B).
