Timing Belt: Specifications (page 7 of 8)
- Make
- Honda
- Model
- Prelude
- Engine
- L4-1958cc DOHC
- Year
- 1989
- Section
- Timing Belt
MaintenanceSpecifications · page 7 of 8
5. Remove the ignition wires from the valve cover.
6. Remove the engine wiring harness protector from the cylinder head cover.
7. Remove the valve cover.
8. Remove the special bolt, then remove crankshaft pulley.
9. Remove the timing belt middle cover and the lower cover.
10. Loosen the adjust bolt, then remove the timing belt.
11. Install in the reverse order of removal.
