Prelude L4-2.2L SOHC (1994)
Timing Belt: Adjustments
CAUTION: Always adjust timing belt tension with the engine cold.
NOTE:
-
The adjuster is spring loaded to properly tension the belt. Do not apply any extra pressure to the belt while performing the adjustment.
-
Inspect the timing balancer belt before adjusting the belt tension.
-
Do not loosen the adjusting nut more than one full turn.
1. Disconnect the alternator terminal and the connector, then remove the engine wire harness from the cylinder head cover.
