Prelude L4-2157cc 2.2L DOHC (VTEC) MFI (2001)
_mfi/Page-1506003.png)
Deflection method:
Apply a force of 98 N (10 kgf, 22 lbf), and measure the deflection between the alternator and crankshaft pulley.
Deflection:
Used Belt: 9.5 - 12.5 mm (0.37 - 0.49 in)
New Belt: 5.5 - 7.5 mm (0.22 - 0.30 in)
NOTE: If the belt is worn or damaged, replace it.
Belt tension gauge method:
