H3 L5-3.7L (2007)
Hydraulic Control Assembly - Antilock Brakes: Service and Repair
Brake Pressure Modulator Valve Replacement
Tools Required
CH-47830 Holding Fixture
Removal Procedure
Caution: Refer to Brake Fluid Irritant Caution.
1. Remove the brake master cylinder assembly (1).
2. Using the CH-47830. install the brake master cylinder assembly in a vise.
3. Remove the brake master cylinder reservoir (3).
