Accent L4-1.6L (2003)
Flex Plate: Specifications
FLYWHEEL
FLYWHEEL
Main Moving System
Drive plate A/T bolt .............................................................................................................................. 120 - 130 Nm (1200 - 1300 kg-cm, 89 - 96 ft. lbs.)
Flywheel bolt: ........................................................................................................................................ 120 - 130 Nm (1200 - 1300 kg-cm, 89 - 96 ft. lbs.)
Standard Value
Flywheel run - out: ............................................................................................................................................................................... 0.1 mm (0.0039 inch)
