2. Remove the engine support bracket. (14 mm bolt and 2 nuts, 17 mm bolt)
3. Remove the power steering belt.
4. Remove the air conditioning compressor belt.

5. Remove the alternator belt.

6. Remove the coolant pump pulley.

7. Remove the crankshaft pulley.
