Accent GL Hatchback L4-1.6L (2002)
8. Remove the timing belt cover.
9. Move the timing belt tensioner pulley toward the coolant pump and temporarily secure it.
10. Remove the timing belt.
NOTE: If the timing belt is reused, mark with an arrow to indicate direction of rotation (on the front of the engine) to make sure that the belt is
reinstalled in the same direction as before.
11. Remove the camshaft from the camshaft sprocket.
12. Remove the crankshaft sprocket and flange.
13. Remove the timing belt idler.
