Timing Belt: Specifications (page 8 of 14)
- Make
- Hyundai
- Model
- Accent GL Hatchback
- Engine
- L4-1.6L
- Year
- 2002
- Section
- Timing Belt
MaintenanceSpecifications · page 8 of 14
14. Remove the timing belt tensioner.
INSPECTION
SPROCKETS TENSIONER PULLEY, AND IDLER PULLEY
1. Check the camshaft sprocket, crankshaft sprocket, tensioner pulley, and idler pulley for abnormal wear, cracks, or damage.
Replace as necessary.
2. Inspect the tensioner pulley and the idler pulley for easy and smooth rotation and check for play or noise. Replace as necessary.
3. Replace the pulley if there is a grease leak from its bearing.
INSPECTION
TIMING BELT
1. Check the belt for oil or dust deposits. Replace, if necessary.
