Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
3. When connecting the control cable to the transaxle mounting bracket, install the clip until it contacts the control cable, in position switch in the
figure.
4. Install the bolt-washer assembly, nut.
5. Install the clip pin, self lock pin. (shift lever side).
6. Connect the position indicator light connector, the O/D switch connector, the parking position switch connector, normal/ economy select switch
connector and the shift lock solenoid connector.
7. Install the shift lever indicator assembly.
8. Apply the specified grease at the place shown in the figure.
Specified grease: Multipurpose grease SAE J310, NLGI No.2
