Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
9. Disconnect the clutch tube (Release cylinder side).
INSPECTION
1. Check the clutch hose or tube for cracks or clogging.
INSTALLATION
1. Connect the clutch tube (Release cylinder side).
2. Temporarily tighten the flare nut by hand, and then tighten it to the specified torque, being careful that the clutch hose does not become twisted.
Tightening torque
Clutch tube flare nut: 13 - 17 Nm (130 - 170 kg.cm, 9 - 13 ft. lbs.)
3. Install the clutch line and clips.
