Page 3
background image

4. Install the master cylinder.

5. Apply the specified grease to the clevis pin and washer.

Specified grease: Wheel bearing grease SAE J310a, NLGI No.2

6. Install the push rod to the clutch pedal.
7. Refill the clutch master cylinder with fluid.
8. Bleed the system.
