Cruise Control Servo: Service and Repair
- Make
- Hyundai
- Model
- Elantra
- Engine
- L4-2.0L
- Year
- 2004
- Section
- Cruise Control Servo › Service and Repair
Cruise ControlService and Repair · page 1 of 2
Cruise Control Servo: Service and Repair
CRUISE CONTROL UNIT AND CABLE
1. Loosen the locknuts (A) and disconnect the actuator cable (B) from the throttle linkage (C).
2. Disconnect the cruise control unit connector (D).
3. Loosen the three mounting bolts (E), and remove the cruise control unit with the bracket (F).
Pinch or Ctrl + scroll to zoom. Double-tap to reset.
