Elantra GLS Wagon L4-2.0L (2000)
When the timing belt is installed on the camshaft sprocket, make sure that the tension side is tightened by pushing the timing belt tensioner pulley
toward the water pump.
6. Turn the crankshaft one turn in the operating direction (clockwise) and realign crankshaft sprocket timing mark.
CAUTION: Do not turn the crankshaft in a counterclockwise direction. The crankshaft should be turned smoothly.
Tightening torque
Tensioner pulley installing bolt: 43-55 Nm (430-550 kgf-cm, 32-41 ft. lbs.)
