Elantra GT Hatchback L4-2.0L (2002)
8. Loose the tensioner bolt of pivot side and slot side.
9. Rotate the crankshaft clockwise as many as 2 teeth of sprocket.
NOTE: Set the exhaust valve rocker arm to upper position of cam in order to be the specified tension.
10. Check that the teeth of sprocket and belt coincide with each other.
11. Tighten the bolt of slot side at first and then tighten the bolt of pivot side.
12. Install the timing belt tension.
13. Install the spark plug.
14. Install the timing belt upper cover.
15. Install the water pump pulley and engine support bracket.
