Elantra Sedan L4-1.8L (1997)
7. Turn the crankshaft one turn in operating direction (clockwise) and realign crankshaft sprocket timing mark.
CAUTION: Do not turn the crankshaft in a counterclockwise direction. The crankshaft should be turned smoothly.
Tightening torque:
Tensioner pulley installing bolt: 43-55 Nm (430-550 kg.cm, 32-41 ft. lbs.)
8. Then recheck the belt tension. The tension side of timing belt is pushed in horizontally with a moderate force [approx. 2 kg (20 N, 5 lbs.)], the
timing belt cog end is approx. 4-6mm (0.16-0.24 inch) away.
9. Install the timing belt cover.
Tightening torque
Timing belt cover bolt: 8-10 Nm (80-100 kg.cm, 6-7.4 ft. lbs.)
10. Install the crankshaft pulley. In this case, make sure that the crankshaft sprocket pin fits the small hole in the pulley.
Tightening torque:
Crankshaft pulley bolt: 170-180 Nm (1700-1800 kg.cm, 125-133 ft. lbs.)
11. Install the coolant pump pulley.
12. Install the drive belt and adjust the belt tension.
