Santa Fe L4-2.4L (2001)
Compressor Pulley: Testing and Inspection
CHECKING THE CLUTCH AIR GAP
1. Check the air gap between the clutch hub and pulley contact surface using a feeler gauge. Clutch air gap 0.35 - 0.65 mm
2. Check the gap around the pulley at 3 points.
3. If the clutch air gap is outside the normal range, correct it using a shim of proper size.
