Santa Fe V6-2.7L (2003)
3. Rotate the tensioner arm clockwise (about 14°) with a spacer (16 mm) and fit the belt to the idler pulley.
4. When installing the belt on the pulley, make sure it is centered on the pulley.
5. The tensioner mark should be between the "MIN" and "MAX" position. If not, replace the belt.
