Timing Belt: Technical Service Bulletins (page 10 of 10)
- Make
- Hyundai
- Model
- Sonata
- Engine
- L4-2.4L
- Year
- 1990
- Section
- Timing Belt
MaintenanceTechnical Service Bulletins · page 10 of 10
(21) Check to ensure that clearance exists when center of belt span on tension side and seal line of under cover are held between thumb and
forefinger as shown in image. Clearance "C" between belt and seal line approximately 14 mm (0.55 in).
13. Install the timing belt covers.
14. Install the crankshaft pulley and cranking adapter, and then tighten bolts to the specified torque. 20 - 29 Nm (200 - 300 kg) (14 - 22 ft lb).
