Wheel Fastener: Specifications

Wheel Lug Nuts

When using an impact gun, final tightening torque should be checked using a torque wrench.

Tightening order. Check the torque again after tightening the wheel nuts diagonally.

Torque ......................................................................................................................................................  0 - 110 Nm (9 - 11 kgf-cm, 65.1 - 79.5 ft. lbs.)
