Compression Check: Specifications



Compression (at 250-400 rpm)

14.5 kg.sm.2 (1.47 Mpa, 213 psi)







Pressure Differential between Cylinders

1.0 kg.cm.2 (100 kPa, 14 psi)







Minimum Pressure

13 kg.cm.2 (1.37 Mpa, 199 psi
